12 Lead CEG Machine with 10.2" Touchscreen and Thermal Printer
Experience the next level of cardiac diagnosis with our advanced 12-lead machine. This ECG Machine is designed for precision, portability, and performance. The Machines come with a high-quality 216mm thermal printer. This ECG machine provides synchronisation printing. offers automatic measurements, and waveform analysis – all these functions can be accessed through a 10.2″ colour touchscreen, which supports both button and touch operation.
This ECG machine is built to provide support for modern hospitals and clinics. Machine supports USB flash drive, SD memory card, and RS 232/USB connectivity to keep backups of the essential data to review, store and print at any time.
Features of The Technocare ECG Machine
The ECG machine comes with different features like
- Comes with 10.2″ colour touch screen with push buttons and touch control.
- 216mm thermal printer with 7-level print thickness settings
- 12-Lead ECG Synchronous Sampling System with auto analysis
- Built in Lion Battery (14.8V, 4000mAh) and Supports AC/DC operation
- Sleep Mode to save power and Extend life of the LCD
- Machine has portable, compact design with a hidden handle
- It offers patient info entry and historical data review functionality
- Lead off and paper detection alarms helps for uninterrupted diagnostics
Technical Specifications of The Technocare ECG Machine
- CMRR: >100dB (With AC filter)
- Input Impedance: >50MΩ
Voltage Tolerance: ±500mV - Sampling Rate: 8000Hz
- Resolution – 12bit
- Frequency response: 0.05Hz-150 Hz
- Operation Modes: Manual and Auto
- Noise Level: <15µVpp: Drift filter: Anti Drift system
- Paper Speed: 12.5,25,50mm/m(±3)
- Sensitivity: 5, 10, 20 mm/mV
- Patient leakage Current: <10µA
- Battery: Built in Rechargeable Li-Ion (14.8V, 4000 mAh)
- Power Supply: 110-230V, 50/60Hz
- Dimensions: 365mm x 306mm x 109mm
