Technocare ECG Machine 03 -Portable 12 Lead ECG System
The Techno care ECG machine 03 is the best compact, efficient and feature-rich 12-lead ECG machine, which is designed for accurate cardiac diagnostics in hospitals, clinics, and mobile healthcare setups. Comes with 5.7″ colour touchscreen, dual operation interface, and easy data handling capabilities.
Features of the Techno care ECG Machine
- 12 Lead ECH Synchronous Sampling: This machine provides high resolution cardiac waveform in real time
- 5.7″ Colour Touch Screen: Easy and user-friendly interface with touch and push button operation
- Built-in Thermal Printer: Comes with 80 mm print width with synchronisation printing for clear, fast reports.
- Advanced Data management: This machine supports USB Flash Drives and SD memory cards for easy data storage and transfer
- Report Formats: You can export ECG Machine in JPG PDF Formats
- PC Connectivity: you can transport data via RS232 or USB for view and print on a computer
- Rechargeable Li-Ion Battery: Insure AC/DC Operation with long-lasting backup ideal for mobile use,
- Portable Design; Built-in Hidden handle and lightweight body make it easy to carry between locations.
Technical Specifications of the Techno Care ECG Machine
- Display: 5.7″ Color CLD display with Touch Support
- Sampling Sysytem: 12 Lead Synchronous ECG
- printing: 80 mm Thermal Printer; 7 level adjustable print density
- Storage: Supports USB and SD card storage
- Connectivity: RS232 and USB for PC data transmission
- Power Supply: 110-230V AC, 50/60 Hz with built in Li-ion battery
- Sleep Mode: Energey saving features to extend CLD Life
- Smart Alerts: lead off and no paper detection features
- Operation Modes: Auto Measurement calculation, waveform freeze, historical data review.
Detailed Specification of The ECG Machine
- CMRR: ≥ 100 dB, with AC Fitter
- Input Circuit: Floating, Protection against defibrillator effect
- Input Circuit Current: ≤ 0.1 µA
- Resolution: 12 bit /1000 Hz
- Operation Mode: Manual / Auto
- Filter: AC, ECG filter
- Drift Filtor: Anti Drift System
- Input impedance: > 50 MΩ
- Patient Current Leakage: < 10 µA
- Specifications of Fuse: T1.6A 250V 5-20
- Recording Paper: Thermal Recording Paper
- Calibrating Voltage: 1mV±3%
- Voltage Tolerance: ± 500 mV
- Time Constant: >3.2s
- Frequent Response: 0.05 Hz – 150 Hz
- Noise Level; ≤ 15 µVp-p
- Threshold: ≤ 20µ V
- Paper Speed: 25, 50 mm/s (± 3%)
- Sensitivity: 5, 10, 20 mm/mV
- Recorder: High-resolution thermal printer
- Battery: Li-ion battery (11.1V, 3800 mAh)
- Dimension: 360 mm x 250mm x 68mm
