Contec ECG Machine 1200G: Advanced 12-lead Diagnostic ECG System
The Contec ECG Machine 1200G is the best electrocardiograph designed for hospitals, clinics, and diagnostic centres. This 12-lead ECG Machine provides the best performance and accurate monitoring and is equipped with innovative features to enhance diagnostic efficiency and user convenience.
This 12-channel ECG machine comes with a high-resolution 800 x 600 dots colour LCD that offers a crystal clear display of ECG waveforms. It comes with a user-friendly interface with quick access buttons that help to switch between automatic and manual recording modes, catering to various clinical needs with multi-language support.
ECG Meaning and What is ECG Test?
ECG stands for Electrocardiogram. An ECG test is a quick and painless test that shows the heart’s electrical activity on a screen or paper. It helps in checking heart rate, rhythm, and any irregular heartbeats.
Features of the Contec ECG Machine- 12 Channel
- The ECH machine comes with high resolution display 800 x 600 colour LCD for clear waveform display
- It offers manual and automatic recording modes, with lead switching and waveform measurement.
- defibrillation protection and floating input design for patient safety
- Comes with Auto measurement of ECG parameters including HR, P-R interval, QRS duration, Q-T interval and more
- The premium EMG Filter (25Hz/35Hz) is provided for noise reduction and accurate interpretation
- The machine comes with a thermal printing system and a 210 mm wide high-speed thermal paper
- Contec offers different customizable speeds from 5mm/s to 50mm/s with ±5% accuracy
- It comes with Rechargeable Lithium battery (DC 14.8V, 3700mAh) With AC 100-240 V Support for flexible operation
- Compact Dimensions: Length 334mm, Width 320mm, 6 Height 85mm
Technical Specifications
- Input Way: Floating With Defibrillator protection
- Leads: Standard 12 Leads
- Patient Leak Current; <10µA
- Input Impedance: ≥50MΩ
- Frequency Response: 0.5Hz – 150 Hz (-3dB – +0.4dB)
- Time Constatnt: ≥3.2s
- CMRR: >60dB: >100dB with filter
- Noise Level: ≤15µVp-p
- Safety type: class 1.CF applied part with defibrillation and pacing protection
- Enduring Polarisation Voltage: ±500 mV
This Contec ECG machine is ideal for the diagnosis in emergency rooms, cardiology departments, ICUs, and outpatient clinics. The Contec 1200G ECG Machine offers dependable and perfect cardiac data capture
What is ECG Machine Used For?
The ECG Machine is used for.
- Detecting heart problems like arrhythmia or heart attacks
- Monitoring heart health during surgeries
- Regular heart check ups for patients with high BP or diabetes
- Checking chest pain or shortness of breath
It is a very important test done in clinics, hospitals and ambulances to detect the primary issues.
ECG Machine Parts
A standard ECG Machine Includes
- Display Screen
- Control Panel or Buttons
- ECG Electrodes (stickers placed on body)
- ECG Paper (prints the report)
- Wires and Cables
- Power Supply or battery
These parts of the ECG machine work to give clear, accurate reports.
ECG Machine Information
- This machine is also known as the Electrocardiogram Machine
- Shows heart rhythm on screen or paper
- The machine is useful for both emergency and routine heart checks
- comes in both standard and portable ECG machine options
- Easy to use with simple controls
ECC Machine Working
The work of this ECG machine is simple. The examiner needs to attach the electrodes to the chest, arms, and legs of the patients. This machine collects the heart’s electrical signals and sends them to the machine, which shows the signal as waves on a screen or prints it on ECG paper.
ECG Electrodes and ECG Paper
- ECG Electrodes are sticky placed on the body to collect signals
- ECG paper is a graph paper where the results are printed; both are important for taking proper readings. Always use the high-quality ECG accessories for the best results
ECG Machine Price in India
At Procare we provide the best quality and affordable ECG Machines. The ECG Machine price in India starts from ₹16000 and goes up to ₹85000, depending on the model (1-channel, 3-channel, 6-channel, or 12-channel), brand, features and portability.
